CBCB-LHN

70-280BAR — Counterbalance Valve (T-11A, 60 L/min)
Motion control valve, cartridge cartridge for hydraulic circuits. 3-PORT COUNTERBALANCE VALVE CBCB-LHN, CAVITY: T-11A, CAPACITY: 60 L/MIN, PILOT RATIO 1,5:1, RANGE: 70-280BAR.
Key specifications
- Cavity / interface: T-11A, Cavity mounted
- Flow capacity: 60
- Working pressure: 350 bar
- Adjustable pressure range: 70–280 bar

Recommended housings / accessories
- Our recommended housing for this cartridge: ECV/S (1 cavity) or YEV/S (2 cavities)
