CBGG-LJN

CBGG-LJN — Counterbalance Valve (T-17A, 240 L/min)
Motion control valve, cartridge cartridge for hydraulic circuits. 3-port counterbalance valve CBGG-LJN, Cavity: T-17A, Capacity: 240 l/min, Pilot ratio 4.5:1, Range: 140-350bar.
Key specifications
- Cavity / interface: T-17A, Cavity mounted
- Flow capacity: 240
- Working pressure: 350 bar
- Adjustable pressure range: 140–350 bar

Recommended housings / accessories
- Our recommended housing for this cartridge: HCX/S (1 cavity) or YJX/S (2 cavities)
