DTAF-MCN

DTAF-MCN — Directional Valve (T-8A, 28 L/min)
Directional valve, cartridge cartridge for hydraulic circuits. DTAF-MCN Capacity: 28 L/min. | Cavity: T-8A .
Key specifications
- Cavity / interface: T-8A, Cavity mounted
- Flow capacity: 28
- Working pressure: 350 bar

Additional information
- This FLeX Series solenoid-operated 2-way, 2-position cartridge is a direct-acting directional poppet valve. Available in either normally open or normally closed configurations, these valves feature a pressure-balanced design, low leakage, and allow flow or blocking in both directions.
