Coil for Series 70 valve

Coil for Series 70 valves. Degree of protection: IP65. Insulation class: F155.

Product number: W0215000151

In stock Out of stock Few in stock

Manufacturer Part No: W0215000151
Product series: Series 70
Type: Coil
Approval: Safe
Voltage (V): 12V DC

Used with Series 70 directional valves.

Key data:
- Voltage: —
- Power: 2 W (DC) / 3.5 VA (AC).
- Voltage tolerance: ±10 – 15 %.
- Insulation class: F155.
- Protection degree: IP65 (DIN 40050 with connector DIN 43650 B-IND).
- Ambient temperature: max 55 °C at 100 % ED.
- ATEX 2014/34/EU rule group 2, category 3 GD (if applicable).

Mounting:
- Slide onto the valve armature and secure with clip or nut.
- Avoid prolonged exposure to atmospheric agents.

Standards/Certificates:
—
