See datasheet for more configurations, max cooling power 5000kW and max flow 2200 l/m..
- .
- The Hybrid series is a logical further development of a shell & tube heat exchanger for a wide range of industrial applications.
- Aluminium fins, which are pushed over the tube undle, connected by force, lead to an increased heat exchange surface.
- This is why the series is so efficient.
- The hybrid-design series is able to reach a heat output up to 5000 kW with a smaller footprint than a bare tube cooler.
- .
- .
- Product features: .
- Aluminium fins ensure a larger heat exchange surface.
- Heat output capacity up to 5000 kW.
- Tube side (Water): flow rate up to 2200 l/min.
- Removable end caps for easy cleaning of the tubes.
- Max.
- pressure: oil 35 bar / water 16 bar (higher pressure on demand).
- High-quality materials.
- Tested five times during production
